Introduction
360° specs are for Cricket Australia Event Presentation content only.
Tile spec can also be used for this allocation.
The 360° Perimeter LED asset refers to the digital signage covering the full canvas of ground level LED.
Submission & Deadlines
All content is submitted via our content management portal MKTG Drop.
Instructions for uploading and re-using content via MKTG Drop can be found here..
Digital content deadline
Print deadline
6 weeks before first display
6 weeks before first display
Contact MKTG immediately if you are unable to meet these deadlines.
Late content may not be able to be displayed.
360° Perimeter LED specs
The 360° spec creates unique content for each section of the LED around the stadium.
This asset must be animated and not have any stationary components ie. content should have a horizontal scroll. This is to account for the Sight Screen blackouts, end of wicket LED and any physical stadium breaks.
Some moments may loop several times when played, so we recommend making your content seamlessly loop back to the start.
You will need to create 14 consecutive tiles for this spec, and 12 for Perth Stadium.
Review and follow our best practices guide to ensure your content displays correctly at the stadium. Example videos and images are available for reference..
Standard Dimensions
| Venues | Dimensions | Tiles |
|---|---|---|
|
All except Perth Stadium |
4,000 x 96 |
14 |
Perth Dimensions
| Tile | Dimensions | Location |
|---|---|---|
|
1 |
3864 x 118 |
Field LED |
|
2 |
||
|
3 |
||
|
4 |
||
|
5 |
3840 x 96 |
End of wicket LED |
|
6 |
3850 x 118 |
Field LED |
|
7 |
||
|
8 |
||
|
9 |
||
|
10 |
3884 x 96 |
|
|
11 |
End of wicket LED |
|
|
12 |
Field LED |
File format
| FPS | File type | Codec | In-break duration |
|---|---|---|---|
|
30 |
.mp4 |
H.264 |
Unspecified |
MKTG Drop assets
| Venue | MKTG Drop Asset |
|---|---|
|
All except Perth Stadium |
Perimeter 360 - Standard 30 |
|
Perth Stadium |
Perimeter 360 Animation only - Perth 30 |
All content is submitted via our content management portal MKTG Drop.
Instructions for uploading and re-using content via MKTG Drop can be found here..
Examples
